Light weight watcher AE16 CPU

Light weight watcher AE16 CPU. - Assessment Unit AE16. - For a more accurate measurement, the module AE16 light tells you the weight in tons, pounds and%. Connected to a PC via USB, you can control the module AE16, recover data thanks to a free and downloadable on the net. AE16 can be installed in the cabin, duct, or in the control room of the elevator. It easily adapts to all situations . - Works with all lifts up to 16 cable diameter of 4-13 mm. - Very compact: 110x30x12 mm. - Very easy to install (no tools required for installation). -. - Features Light Weight watcher AE16. - Input: 16. - Power supply: 12-28 VDC. - Power: 0.8W. - Relay output programmed: NO + 3 NC contacts. - Analog Output: optional. - Display: LED 5 lights. - Operation: 3 pushbuttons. - Dimensions: 105x90x62 mm. - Sensors: light LS. - Dimentions strings: 4-13 mm. - Measuring range: 0-500 kg. - Method of measurement: strain gauge. - Pre-calibration:. - Calibration under: X. - Temperature: 0-70 ° C. - Cable length: 2.5 mm. - Dimensions (LxWxT): 110x70x22 mm. Old Reference: AE16
